Foglio metallico colorato con colore pre-verniciato
$600≥400Ton
Tipo di pagamento: | L/C,T/T |
Incoterm: | FOB,CFR,CIF |
Quantità di ordine minimo: | 400 Ton |
Trasporti: | Ocean |
Porta: | Shandong,Shanghai,Tianjin |
$600≥400Ton
Tipo di pagamento: | L/C,T/T |
Incoterm: | FOB,CFR,CIF |
Quantità di ordine minimo: | 400 Ton |
Trasporti: | Ocean |
Porta: | Shandong,Shanghai,Tianjin |
Modello: ASTM, JIS, GB, AISI, DIN, BS
Standard: AiSi, ASTM, bs, DIN, GB, JIS
Luogo D'origine: Cina
Specie: Lamiera di acciaio
Processo Produttivo: Laminati a freddo
Trattamento Della Superficie: Zincato
Applicazione: Piastra caldaia, Piatto contenitore, Piatto della nave, Flangia Piastra
Acciaio Speciale: Acciaio al silicio, Acciaio resistente all'usura, Piastra in acciaio ad alta resistenza
Tolleranza: ± 1%
Categoria: Lamiera di acciaio laminata a freddo, Lamiera di acciaio zincata a caldo, Lamiera di acciaio elettrozincata, Piastra a bassa lega, Piastra del recipiente della caldaia, Lamiera di acciaio al galvalume, Piatto a scacchi, Lamiera di acciaio rivestita di colore, Piatto d'acciaio della nave, Lamiera di acciaio laminata a caldo, Lamiera di acciaio
Servizio Di Elaborazione: Flessione, Saldatura, Decoiling, Taglio, Punzonatura
Unità vendibili | : | Ton |
Tipo pacchetto | : | Imballaggio degno di mare standard |
The file is encrypted. Please fill in the following information to continue accessing it
Products |
Ral Color Coated SGCC GI Prepainted Galvanized Steel Coil PPGI |
|
Substrate |
Hot dip galvanized, Galvalume, Aluminium... |
|
Thickness |
0.12-2.0mm |
|
Width |
600-1250mm ( Normal:1250, 1220, 1200,1000,914 mm) |
|
Coil weight |
3-9 tons or as your requirement. |
|
ID |
508/610 mm |
|
Coating |
Zn coating |
AZ coating |
|
30-275g/m2 |
30-275g/m2 |
Grade |
Galvanized |
Galvalume |
|
DX51D+Z, DX52D+Z, DX53D+Z, |
DX51D+AZ, DX52D+AZ, DX53D+AZ, |
Top Paint |
10-25 micron(Normal:10-12mic) |
|
Back paint |
5-12 micron(Normal:5-7mic) |
|
Coating type |
Top paint: PE, SMP, HDP, PVDF, PU |
|
|
Functions: Decorative, Machinability, Weather resistance, Scrath |
|
|
Primer paint: Polyurethane, Epoxy, PE |
|
|
Functions:Machinability, Corrosive resistance, Adhesion, Scrath |
|
|
Back paint: Epoxy, Modified polyester |
|
|
Functions: Scrath resistance, Bending adhesion, Corrosive resistance |
|
Type of |
Front: Doulbe coated & double drying |
|
|
Back: Double coated & double drying, single coated & double drying |
|
|
Double coated & double drying is used for corrugated sheet |
|
|
Double coated & single drying is for sandwich panel |
|
Packing |
Standard export package .Plastic film in the first layer,second layer is Kraft |
|
Application |
Building industry ,structural use, roofing, commercial use ,household |
